Aiphone LE SSA Door Station

Description

Aiphone LE SSA Door Station

Stainless Steel Door Station – The Aiphone LE SSA Door Station is a vandal proof and weather resistant sub station. It’s constructed with 12 gauge stainless, a baffle protected speaker and limited stop call button. The unit either flush mount into a 2-gang box, or surface mount with the SBX-2G. The LE-SS/A includes tamper proof screws and a tool for installation.

This is a door station only and requires:

• Any of the master stations- LEM-1DL or LEM-1DLC .
• Power Supply- PT-1210N

If you want a complete set then you can get the LEM-1DLS

Specification

Power Source: 12~16V AC – Use PT-1210N 12~24V DC, 200mA.
Communication: When called by tone, press TALK to reply, press door release button to release door and press OFF for standby.
Door Release: Contact rating 30V AC or DC, 1A.
Wiring: Door/Sub to master: 2-cond., overall shield.
Distance: Door/Sub to farthest master: 650(22AWG) 1,600(18AWG).
Wire Type: Aiphone #822202 or Aiphone# 821802.

Warranty
Aiphone warrants its products to be free from defects in material and workmanship under normal use and service for a period of one, two, or three years (depending on the product) after installation to the ultimate user. Proof-of-purchase is required to verify warranty period, otherwise warranty will be based on product lot code.

Product Documents

Review the manufacturer documents before ordering or installation to confirm compatibility, preparation, and current requirements.

• Aiphone LE-SS/A installation instructions (PDF)
• Aiphone LEM-1DL supplemental wiring and application instructions (PDF)
