SDC Stand Alone Indoor Keypad 918U 12/24 VAC/DC Satin Stainless Steel Flush Mount

Sale!
SDC918U Stand Alone Keypad Flush Mount

SDC Stand Alone Indoor Keypad 918U 12/24 VAC/DC Satin Stainless Steel Flush Mount

Original price was: $230.00.Current price is: $169.95.

SDC 918 EntryCheck™

Model918U
Users500 user codes
Power12/24 VAC/DC
Current30mA Typical, 150 mA Maximum
OutputRelay 1 – SPDT 2 Amps @ 30VDC
Relay 2 – SPDT 2 Amps @ 30 VDC
SKU: SDC 918U Categories: , , Tags: , Brand:

Description

SDC 918 Series Indoor Digital Keypad

designed to control access of a single entry point for facilities with up to 500 users. Each user is assigned a personal identification number (PIN). Keypad entry of a valid one to six digit code activates one or both of the output relays which releases an electric door lock.

Standard Features

  • 12-key illuminated, moisture-resistant keypad
  •  Thick stainless steel faceplate
  •  Tamper-resistant screws
  •  Keypad programmable
  •  Tactile keys with selectable audible levels
  • for key depression or output activation
  •  Adjustable audible annunciation
  •  Visual status indicators (LED)

Self Contained Keypads Only

  • 500 user codes
  •  4 outputs, 2 relay and 2 solid state
  •  Outputs timed or latching (on/off)
  •  Assign entry PIN’s to relays 1 and/or 2
  •  Choice of door sense or relay inhibit input
  •  Timed anti-passback, anti-tailgate
  •  Keypad tamper lockout
  •  Request-to-exit (REX)

Applications

  • Single gang wall mount



Dual LED Status Indicator

  • Configurable illumination: on, off, timed
  • LED status: access, lockout



Self Contained Keypad Programming Options

SDC’s EntryCheck™ keypads includes a door sense/inhibit input feature. When programmed for “door sense”, a door position status (DPS) swtich wired into the
input and detects a “forced entry” or “door ajar” condition. When programmed for “inhibit Input”, a maintained switch or automatic timer wired into a the input will disable the activation of the main relay.

EntryCheck™ keypads also have a request-to-exit (REX) input for connection to an exit switch and/or fire access key switch for fire/emergency access. When
access is granted, the shunt option is activated shunting alarm contacts on the door or gate. This prevents triggering of an alarm during authorized access.

Additional information

Weight1 lbs
Dimensions5 × 4 × 3 in
